SWELL Acoustical Panels™
A series of individual modular panels that can be configured in a variety of patterns, using a combination of our standard widths.
SWELL is available in 2”, 4”, 6”, 8”, & 10” standard widths and can run vertically or horizontally. Use one width per wall, or mix multiple widths on one wall for maximum creativity.
-
Content Substrate, Plywood, Fabric
Fabric Compatible with felt and felt-like fabrics. Explore the suppliers on our Resources page to find the fabric that is suitable for your next project.
Panel Widths 2”, 4”, 6”, 8”, 10” (1” Element)
Panel Depths 2 3/8” (4” SWELL also available in 1 3/8”)
Standard Length Up to 120”. Oversized lengths available
Mounting Options Construction adhesive and nails
Lead time 5-7 weeks
Fire Rating California Technical Bulletin 117 2013; NFPA 260+ UFAC Class 1
Acoustic Rating ASTM C423: NRC 0.95, SAA 0.97
-
