For fabric wrapped solutions, Baffles are compatible with most fabrics.

Product Linear Ceiling Baffles

Composition 100% Polyester Fiber (PET)

Baffle Thickness 0.35” (9mm) + attachment piece, 0.47” (12mm), 0.94” (24mm), 1.96” (50mm)

Baffle Height 4”, 6”, 8”, 10”, 12”

Maximum Length 120”

Environmental Contains 75% previously recycled polyester fiber

Colors Click here to view all 95 available colors

Method V Track

Contents PET Baffle, V-Track, Aircraft Cable (suspension only)

Maximum Width 70” (Track-To-Track)

Track Length 118” (custom lengths up to 135” available upon request)

Standard Spacing 6” Between Baffles (custom spacing available)

Lead Time 6-8 weeks

Mounting Suspended or Direct

Method Cable to Unistrut (by others)

Contents PET Baffle, Gripper, Cable, Strut Channel Nut, & Unistrut (by others) Threaded Rod (by others) can be substituted in field

Cable Length 24”, 48”, 60” (can be cut to size in field)

Cable Spacing 12” in from each end of the Baffle

Lead Time 6-8 weeks

Mounting Suspended

Method Cable to Deck

Contents PET Baffle, Gripper, Cable, Two Piece Cable Coupler w/ 1/4”-20 Female Thread Attachment to ceiling (by others)

Cable Length 24”, 48”, 60”, & 240” (can be cut to size in field)

Cable Spacing 12” in from each end of the Baffle

Lead Time 6-8 weeks

Mounting Suspended
